Air Operator Sizing Data

Air to Close Sizing Data for Piston and Diaphragm Operators

When using pneumatic valve operators it is important to know the design requirements. These tables provide operating limits as well as flow coefficients and stem travel.

FEATURES

Required operator air pressure at various system pressures.
Maximum operating pressure.
Stem travel.
Flow coefficients.

BENEFITS
These tables are used when design systems and specifying air actuated valves. The tables show the air pressure required to close valves, at different operating pressures, and for the different size operators.
