Gate Valves Bolted Bonnet Full Port

1500 Lb. 2500 Lb.



Design construction:

ASME B16.34 - BS 5352
Outside Screw and Yoke (OS&Y)
Self aligning two piece packing gland
Integral backseat
Oval ring joint gasket
Socket Weld Ends to ASME B16.11
Screwed Ends (NPT) to ASME B1.20.1
Butt Welding Ends to ASME B16.25

Ratings standard class:



  • carbon steel class 1500 3705 psig @ 100°F


                          255 bar + 38°C



  • carbon steel class 2500 6170 psig @ 100°F


                          425 bar + 38°C
